PURELAB Chorus 2 +
One complete solution for the laboratory
The PURELAB Chorus 2+ provides additional bacteria and inorganic quality for sensitive analytical and life science applications above that of basic laboratory work. With its simple design and ease of use, water can be dispensed from the system or from a choice of additional Dispensers.
"I am so grateful for your assistance with our Chorus 2+ RO system. I’ve saved our department thousands of dollars!"
Features
PURELAB Chorus 2+ (RO/EDI/UV)
This product features our patented recirculating EDI technology: the only EDI system on the market that is able to fully recirculate to maintain >15 MΩ.cm.
- Fully Recirculating EDI ELGA’s patented fully recirculated EDI provides a constant supply of high purity that guarantees a minimum of 15 MΩ.cm water at all times.
- Ideal for High Volume Labs A cost-effective solution for laboratories requiring higher output volumes thanks to the incorporated EDI technology.
- Single System Solution Perfect single system solution for analytical and life science applications requiring >15 MΩ.cm.
- Reduced Maintenance Times Quick and easy replacement of consumables to reduce maintenance times.
- Space Saving Design Designed to be modular and stackable to save space, whether wall-mounted or under the bench.
- Data Capture Data capture via USB for system performance validation and software updates.
Ideally suited for: Electrochemistry, Cell cultures, Spectrophotometry, Feed to ultrapure water, Media/buffer preparation, General chemistry
● Type II+ Water ● >15 MΩ.cm ● Liters per day: 1 - 120
PURELAB Chorus 2+ (RO/DI/UV)
This product provides tap to 15 MΩ.cm pure water for laboratories requiring up to 100 liters per day and is able to fully recirculate to maintain 15 MΩ.cm.
- Fully Recirculating In addition to simple composite vent filtration, the PURELAB Chorus 2+ is the only fully recirculating Type II+ pure water system on the market, maintaining consistent peak water purity at 15MΩ.cm.
- Configuration Ability to configure multiple systems to increase flow rate and save space through stackable solutions that can be wall mounted, on or under the bench.
- Simplicity Simple to install, operate and maintain, with a clear indication of water purity. It is also simple to replace consumables, reducing maintenance time.
- Data Capture Data capture via USB for system performance validation and software updates.
- Dispense Choose from three different Halo Dispense solutions to allow additional dispense points, even in adjacent labs.
Ideally suited for: Electrochemistry, Spectrophotometry, Feed to ultrapure water, Media/buffer preparation, General chemistry
● Type II+ Water ● >15 MΩ.cm ● Liters per day: 1 - 10
Tech Specs
| PRODUCT SPECIFICATIONS | PURELAB CHORUS 2+ (RO/EDI/UV) 10 L/HR | PURELAB CHORUS 2+ (RO/EDI/UV) 20 L/HR |
|---|---|---|
| Inorganics (resistivity at 25°C) | 1 to >15 MΩ.cm | 1 to >15 MΩ.cm |
| Organics (TOC) | <10 ppb | <10 ppb |
| Bacteria | <0.001 CFU/ml† | <0.001 CFU/ml† |
| pH | Effectively neutral | Effectively neutral |
| Particles | >99% rejection | >99% rejection |
| Daily usage (max) | 220 l/day | 440 l/day |
| Daily usage (min) | 1 l/day | 10 l/day |
| Delivery flow rate | 10 l/hr * | 20 l/hr * |
| PRODUCT SPECIFICATIONS | PURELAB CHORUS 2+ (RO/EDI/UV) 10 L/HR | PURELAB CHORUS 2+ (RO/EDI/UV) 20 L/HR |
|---|---|---|
| Inorganics (resistivity at 25°C) | 1 to >15 MΩ.cm | 1 to >15 MΩ.cm |
| Organics (TOC) | <10 ppb | <10 ppb |
| Bacteria | <0.001 CFU/ml† | <0.001 CFU/ml† |
| pH | Effectively neutral | Effectively neutral |
| Particles | >99% rejection | >99% rejection |
| Daily usage (max) | 220 l/day | 440 l/day |
| Daily usage (min) | 1 l/day | 10 l/day |
| Delivery flow rate | 10 l/hr * | 20 l/hr * |
* Standard conditions are 4 bar inlet pressure at 15 ⁰C, fed with potable water and a clean pre-treatment cartridge.
† With POU filter fitter
Consumables
Ions will remain in the water
Potential recontamination of purified water and reduced flow rates
Chlorine, chloarmine and organics remain, increasing the burden on downstream consumables which will need more frequent and expensive changes
High levels of organics and inorganics remain in the water reducing the functional life of the DI pack
Increase in airborne contaminants and potential recontamination of purified water
Accessories
Unrivaled purity design, unmatched flexibility & effortless use.
Together with PURELAB Chorus & Quest, the PURELAB Dispenser enables uninterrupted discovery.
✓ Delivering proof of water purity
✓ Repeated volume dispensing
✓ Improving lab efficiency
✓ Reproducible results
Capacity: 15 liters
Dimensions: 470 (h) x 376 (w) x 340 (d)
Flow Rate: 6 l/min
Capacity: 30 liters
Dimensions: 660 (h) x 376 (w) x 340 (d)
Flow Rate: 8 l/min
Capacity: 60 liters
Dimensions: 570 (h) x 532 (w) x 522 (d)
Flow Rate: 10 l/min
Capacity: 100 liters
Dimensions: 806 (h) x 532 (w) x 522 (d)
Flow Rate: 10 l/min
Modular nature of PURELAB Chorus means that your dispense solutions can sit independently from the unit. You can even have them installed in adjacent labs.
✓ Fixed handset
✓ Variable flow rate dispense
✓ Drop-by-drop control
✓ Locked dispense
Modular nature of PURELAB Chorus means that your dispense solutions can sit independently from the unit. You can even have them installed in adjacent labs.
✓ Fixed handset
✓ Variable flow rate dispense
✓ Drop-by-drop control
✓ Locked dispense
✓ Purity monitoring to point-of-use
✓ Auto volume dispense
Modular nature of PURELAB Chorus means that your dispense solutions can sit independently from the unit. You can even have them installed in adjacent labs.
✓ Flexible handset
✓ Variable flow rate dispense
✓ Drop-by-drop control
✓ Locked dispense
✓ Purity monitoring to point-of-use
✓ Auto volume dispense
Unrivaled purity design, unmatched flexibility & effortless use.
Together with PURELAB Chorus & Quest, the PURELAB Dispenser enables uninterrupted discovery.
✓ Delivering proof of water purity
✓ Repeated volume dispensing
✓ Improving lab efficiency
✓ Reproducible results
Capacity: 15 liters
Dimensions: 470 (h) x 376 (w) x 340 (d)
Flow Rate: 6 l/min
Capacity: 30 liters
Dimensions: 660 (h) x 376 (w) x 340 (d)
Flow Rate: 8 l/min
Capacity: 60 liters
Dimensions: 570 (h) x 532 (w) x 522 (d)
Flow Rate: 10 l/min
Capacity: 100 liters
Dimensions: 806 (h) x 532 (w) x 522 (d)
Flow Rate: 10 l/min
Modular nature of PURELAB Chorus means that your dispense solutions can sit independently from the unit. You can even have them installed in adjacent labs.
✓ Fixed handset
✓ Variable flow rate dispense
✓ Drop-by-drop control
✓ Locked dispense
Modular nature of PURELAB Chorus means that your dispense solutions can sit independently from the unit. You can even have them installed in adjacent labs.
✓ Fixed handset
✓ Variable flow rate dispense
✓ Drop-by-drop control
✓ Locked dispense
✓ Purity monitoring to point-of-use
✓ Auto volume dispense
Modular nature of PURELAB Chorus means that your dispense solutions can sit independently from the unit. You can even have them installed in adjacent labs.
✓ Flexible handset
✓ Variable flow rate dispense
✓ Drop-by-drop control
✓ Locked dispense
✓ Purity monitoring to point-of-use
✓ Auto volume dispense
FAQS
- What is a PURELAB Chorus 2+ range?
The PURELAB Chorus 2+ range is designed for customers who need a minimum guaranteed quality of Type II water directly from a tap source. It can produce up to 480 litres of pure water per day.
- What type of applications are suitable for water dispensed from the PURELAB Chorus 2+ range?
The PURELAB Chorus 2+ range is designed for applications including media / buffer preparation, general chemistry, histology, microbiological analysis and electrophysiology.
- What are the benefits of the PURELAB Chorus 2+ range?
The PURELAB Chorus 2+ range is designed for customers requiring high purity Type II (pure) water becauses it guarantees a minimum of 10MΩ-cm . It offers water monitoring up to the point of dispense to help ensure valuable parameters are provided at all times; it provides inbuilt periodic recirculation to help minimise biofilm build up which can affect some applications, it has a low bacterial specification with point of use filters, it has a range of dispensing solutions to suit different applications and budgets as well as the ability to adapt to where there is available space. It is also an easy to use and maintain system.
- How many product variants are available?
The PURELAB Chorus 2+ range offers 8 product variants ; the EDI and DI variants.
- What storage reservoirs are available with the PURELAB Chorus 2+ range?
The PURELAB Chorus 2+ range offers customers a choice of 4 reservoir sizes; 15l, 30l, 60l and 100l.
